J-107 L Surface Planer - S

Standard Accessories :
2 planer blades fitted in cutter block, mitre gauge, motor pulley, motor fixing plate, toolkit & m/c manual.
L = Machine with 61″ long table, LL = Machine with 72″ long table

Technical Specification

Details	Unit	J-106	J-107	J-107 L	J-107 LL
Surfacing capacity	mm / inch	254 / 10"	330 / 13"	330 / 13"	330 / 13"
Length of surface table	mm / inch	1220 / 48"	1295 / 51"	1550 / 61"	1830 / 72"
Rebating capacity	mm / inch	12.5 / ½"	12.5 / ½"	12.5 / ½"	12.5 / ½"
Cutter block diameter	mm / inch	95 / 3.75"	95 / 3.75"	95 / 3.75"	95 / 3.75"
Cutter block speed	rpm	4000	4000	4000	4000
Standard cutter block	code no.	2B	2B	2B	2B
Circular saw table size	mm / inch	610 x 355 / 24" x 14"	610 x 355 / 24" x 14"	610 x 355 / 24" x 14"	610 x 355 / 24" x 14"
Up/Down movement of cir. saw table	mm / inch	75 / 3"	75 / 3"	75 / 3"	75 / 3"
Max circular saw diameter	mm / inch	300 / 12"	300 / 12"	300 / 12"	300 / 12"
Power required	hp / rpm	2 / 1440	2 / 1440	3 / 1440	3 / 1440
Approx. weight	kg	200	250	280	320

PD (Gear Type)
(With ½” Drill chuck & drilling tool) Drilling attachment for Surface Planer :
(It is optional, can be ordered any time separately)

Details	Unit	PD (Gear Type)
Drilling Table Size	mm / inch	280 x 150 / 11″ x 6″
Up/Down movement of table	mm / inch	65 / 2½”
Cross movement of table	mm / inch	100 / 4″
Longitudinal movement of table	mm / inch	150 / 6″
Drill chuck capacity	mm / inch	12.5 / ½”
Approx. weight	kg	70

Cutter Block Selection
