Standard Accessories :
2 planer blades fitted in cutter block, motor pulley, motor fixing plate, V-belt guard, toolkit & m/c manual.
| Details | Unit | J-312 | J-313 |
| Max. planing width | mm / inch | 254 / 10" | 330 / 13" |
| Thicknessing capacity | mm / inch | 177 / 7" | 177 / 7" |
| Length of thickness table | mm / inch | 610 / 24" | 660 / 26" |
| Min. length of workpiece for thicknessing | mm / inch | 254 / 10" | 254 / 10" |
| Feeding speed | feet / min. | 24 | 24 |
| Cutter block diameter | mm / inch | 95 / 3.75" | 95 / 3.75" |
| Cutter block speed | rpm | 4000 | 4000 |
| Standard cutter block | code no. | 2B | 2B |
| Power required | hp / rpm | 2 / 1440 | 3 / 1440 |
| Approx. weight | kg | 175 | 200 |
