Standard Accessories :
Routing work table, R/F switch, 3 nos. different size guide pins, collet – 12 mm hole with 8 mm hole sleeve, motor pulley, motor fixing plate, flat belt, toolkit & m/c manual
| Details | Unit | J-901 |
| Throat clearance | mm / inch | 380 / 15" |
| Spindle vertical movement | mm / inch | 25 / 1" |
| Routing work table size | mm / inch | 610 x 420 / 24" x 16½" |
| Up/Down movement of table | mm / inch | 125 / 5" |
| Base table size | mm / inch | 355 x 355 / 14" x 14" |
| Table tilt | degree | 15° |
| Spindle speed | rpm | 11000 |
| Power required | hp / rpm | 1.5 / 2800 |
| Approx. weight | kg | 175 |
