Standard Accessories :
Motor pulley, motor plate, face plate, 3 pin center, revolving – center, V-belt & m/c manual.
| Details | Unit | J-921 - 6 ft. | J-931 - 8 ft. |
| Length of bed | mm / inch | 1825 / 72" | 2435 / 96" |
| Width of bed | mm / inch | 215 / 8½” | 215 / 8½” |
| Height of centers | mm / inch | 203 / 8" | 203 / 8" |
| Admit between centers | mm / inch | 1220 / 48" | 1825 / 72" |
| Approx. spindle speed | rpm | 700 / 1400 / 2800 | 700 / 1400 / 2800 |
| Face plate diameter | mm / inch | 190 / 7½” | 190 / 7½” |
| Power required | hp / rpm | 1 / 1440 | 1 / 1440 |
| Approx. weight | kg | 300 | 350 |
