Standard Accessories :
1 no. electric motor of 3 HP/1440 RPM – 3 phase, ½” chain set, R/F switch, oil bowl, grinding wheel & V-belt fitted in grinding attachment, toolkit & m/c manual.
Note : M/c with 1- phase motor available at extra cost.
| Details | Unit | J-930 (H) |
| Table size | mm / inch | 560 x 255 / 22" x 10" |
| Up/Down movement of table | mm / inch | 89 / 3½" |
| Cross movement of table | mm / inch | 100 / 4" |
| Longitudinal movement of table | mm / inch | 305 / 12" |
| Max. mortise hole size | mm / inch | 15.8 / ⅝" |
| Max. depth of cut | mm / inch | 140 / 5½" |
| Motor power | hp / rpm | 3 / 1440 |
| Total power | hp | 3 |
| Approx. weight | kg | 340 |
