Standard Accessories :
01 no. electric motor of 2 HP-2800 RPM-3 phase, R/F Switch, ½” chisel set, toolkit & m/c manual.
Note : Must use best quality chisel for good performance of machine.
Note : Manual Model J-1920M also available.
| Details | Unit | J-1920 |
| Table size | mm / inch | 530 x 200 / 21" x 8” |
| Max chisel capacity | mm | 6 to 19 |
| Max depth of cut | mm / inch | 89 / 3½” |
| Cross movement of table | mm / inch | 100 / 4" |
| Longitudinal movement of table | mm / inch | 305 / 12" |
| Max height of workpiece on table | mm / inch | 150 / 6" |
| Up/Down movement of table | mm / inch | 89 / 3½” |
| Air pressure required | kg / cm2 | 5 to 7 |
| Motor power | hp / rpm | 2 / 2800 |
| Total power | hp | 2 |
| Approx. weight | kg | 235 |
