Standard Accessories :
01 no. electric motor of 3 HP-2800 RPM-3 phase, 01 no. electric motor of 1.5 HP-1440 RPM-3 phase, control panel, 1″ chisel tool set, Hydraulic power pack set, toolkit & m/c manual.
Note : Must use best quality chisel for good performance of machine.
Note : M/c with 1 phase motor available at extra cost, except machine J-1925.
| Details | Unit | J-1925 |
| Table size | mm / inch | 555 x 240 / 22" x 9½” |
| Max chisel capacity | mm | 8 to 25.4 |
| Max depth of cut | mm / inch | 89 / 3½” |
| Cross movement of table | mm / inch | 89 / 3½” |
| Longitudinal movement of table | mm / inch | 280 / 11" |
| Max height of workpiece on table | mm / inch | 125 / 5" |
| Up/Down movement of table | mm / inch | 125 / 5" |
| Power pack motor | hp / rpm | 1.5 / 1440 |
| Motor power | hp / rpm | 3 / 2800 |
| Total power | hp | 4.5 |
| Approx. weight | kg | 550 |
